Silicon Labs EFM8BB51 y EFM8BB52 MCU Busy Bee de 8 bits

Written by: INCB
Category: Nuevos Componentes , Industria y Noticias

Los MCU Busy Bee de Silicon Labs EFM8BB51 y EFM8BB52 son microcontroladores multifunción con un conjunto completo de características en carcasas compactas. Estos dispositivos ofrecen un gran valor al integrar comunicaciones avanzadas y periféricos analógicos en un espacio pequeño, lo que los hace ideales para aplicaciones con limitaciones de espacio. Con un núcleo 8051 eficiente, capacidad de E/S de 5 V, precisión analógica y modulación de ancho de pulso mejorada, los MCU EFM8BB51 y EFM8BB52 son ideales para aplicaciones integradas. Los MCU Busy Bee EFM8BB51 y EFM8BB52 de Silicon Labs incluyen reinicio en el chip, un monitor de suministro de voltaje, un temporizador de vigilancia y un oscilador de reloj integrado. La memoria flash se puede reprogramar en el circuito, lo que proporciona almacenamiento de datos no volátil y permite actualizaciones de firmware en el campo. La interfaz de depuración en el chip (C2) permite la depuración no intrusiva (no utiliza recursos en el chip) en el circuito utilizando la MCU de producción instalada en la aplicación final. Esta lógica de depuración admite la inspección y modificación de la memoria y los registros, el establecimiento de puntos de interrupción, un solo paso y los comandos de ejecución y parada. Todos los periféricos analógicos y digitales son completamente funcionales durante la depuración.

Clique aquí para ver las hojas de datos
