RZ y 2H placa de evaluación de Rebesas Electronics

Written by: Newton C. Braga
Category: Nuevos Componentes , Industria y Noticias

La placa de evaluación RZ/T2H de Renesas Electronics es una herramienta integral para evaluar el microprocesador RZ/T2H, que incluye todos los circuitos necesarios listos para su uso inmediato. La placa Renesas Electronics RZ/T2H está equipada con un depurador Segger. Admite el desarrollo y la depuración de software a través de una simple conexión USB. Los desarrolladores pueden utilizar el entorno de desarrollo integrado (IDE) e2studio y acceder a varios programas de muestra directamente desde el sitio web de Renesas. La placa admite múltiples modos de arranque, incluidos xSPI Flash, USB, eSD, eMMC y arranque SCI. Cuatro puertos Ethernet (GMAC de 3 canales y conmutador Ethernet) permiten evaluaciones de Ethernet industrial. Además, se conecta a la placa inversora de la serie RZ/T para una evaluación inmediata del control del motor y ofrece escalabilidad a través de interfaces PMOD, mikroBUS, QWIIC y Grove.

Clique aquí para ver las hojas de datos
